Aerfoam 125 Connector

The Aerfoam 125 Connector securely joins Aerfoam ducts to other parts of the system, ensuring an airtight connection while maintaining the system’s insulation performance.

• Ensures airtight and secure connections
• Maintains full insulation performance
• Simple and quick installation without tools
• Compatible with all Aerfoam parts of the same diameter
• Airtightness class D/ATC 2 up +/- 200 Pa, which minimises fan energy use and sound production
• EPD certified and REACH compliant

Specifications

General

Product Name	Aerfoam 125 Connector
Type	Connectors
GTIN	8713645123011
Trade Name	Aerfoam

Technical

Colour	Grey
Material	PP
Internal Duct Dimension	125 mm

Dimensions

Length Gross	181 mm
Width	161 mm
Height	100 mm
Net Weight	0.11 kg

Logistical

Intrastat	39259080
Number per Packaging	1
Base Unit Packaging	Unpacked
Gross Weight	0.11 kg
Packaging / Trade Length	181 mm
Packaging / Trade Width	161 mm
Packaging / Trade Height	100 mm

Performance

CE String

-

Downloads

• Installation manual - Aerfoam System
• Brochure - Aerfoam
• Technical data sheet - Aerfoam Bend, Connector and Wall Bracket
