150mm Mixed Flow Extractor Fan: Vortice Lineo (AC Motor)

Vortice Lineo Mixed Flow Extractor Fans

• Enclosures made of fire resistant plastic resin, E2 class, according with ISO EN 11925-2: 2010, in areas close to motor and electrical components.
• Nominal diameter 150mm.

• Induction motor, thermally protected, with shaft mounted on ball bearing supports, coupled with a centrifugal impeller.
• High water resistance: IPX5 (if installed in a duct).
• Speed adjustable through Vortice speed devices.
• Long life 30,000 hour motor.
• Double insulated housing (does not require an earth).
• Made in Italy.
• 2 Year Warranty.

Versions

Hard Wired

• Requires an electrician for hard wire installation.

• A switch can be installed for 2 speed operation (requires an electrician).

2 Pin Plug and Lead

• Plug and play operation in a standard power point or socket outlet.

• A switch can be installed for 2 speed operation (requires an electrician).

150mm Specifications

Model

• Vortice Lineo 150.


Max Speed

• Maximum absorbed power: 58 W.
• Maximum delivery: 550  m³/h.
• Pressure max: 264.9 Pa.
• RPM: 2,100.
• Sound pressure Lp 3m breakout: 50.5 dB(A).

Min Speed

• Maximum absorbed power: 40 W.
• Maximum delivery: 385 m³/h.
• Pressure max: 206 Pa.
• RPM: 1,580.
• Sound pressure Lp 3m breakout: 41.4 dB(A).

Dimensions

• 214.5mm width (A).
• 234mm height (B).
• 294mm length (C).
• 146mm duct attachment flange diameter (D).

• 2.5kg weight.
